E.8.1.3 Using the Command Line Interface
E.8.1.3.1 CLI Menu System – Parallel Functionality
Chapter 7. FRONT PANEL OPERATION
The CLI, accessible via Telnet and SSH, allows you to change operating parameters in a manner
similar to the functionality as provided for the monitoring, configuration, and control via the
SLM-5650A Satellite Modem's front panel menus (see Chapter 7. FRONT PANEL OPERATION)
and in the NP Module HTTP/HTTPS Interfaces (see Section E.3 Network Processor (NP)
HTTP/HTTPS Interface in this appendix).
E.8.1.3.2 CLI Menu – Common Information, Navigation, Operation Features
Certain operational menu selections (e.g., Vipersat Configuration) are visible/selectable only when
that FAST Option has been purchased and enabled for operation. The menu pages that follow
show all available options as installed – the configuration in use may or may not provide the level of
functionality depicted in this appendix.
With some exceptions, the menu pages depicted in this appendix feature the following common
informational or navigational aids:
Menu Options/Fields
[Text field example]
Save Parameters to Flash
Logout of CLI Session
Exit Menu
Typically, once any mnemonic is entered, the user is prompted to type in a functional selection, an
alphanumeric configuration string, or an operational value. This prompt is provided at the bottom of
the active page and takes the form of a selection choice and/or a blank prompt (a solid bar), as
shown in the example to the right:
Appendix E
Entry
Typically found in the body of the page. This designates the field as a read-
only status/informational message. There is no user action required for this
[RO]
item.
Allows user to save the current configuration of the NP Interface to
S permanent storage. This configuration will be restored on each successive
power cycle.
L Allows user to log out of the CLI session.
Allows user to exit the current menu and return to the parent menu.
X
Alternately, the user may press the Esc key to perform the same action.
E–68
SLM-5650A Satellite Modem
Description
MN-SLM-5650A
Revision 10
