10.3.10 Network Processor (NP) Interface Commands and Queries
The instruction codes that follow are valid only when the optional Network Processor (NP) Interface Module is installed in the SLM-5650A
Satellite Modem.
Controller-to-Target
Instruction Code and
Qualifier
Parameter
Type
Command Query
Router BPM BRT= BRT?
Mode
Router Working GBM= GBM?
Mode
Router Ethernet MIP= MIP?
Interface
Management IP
Address and
Subnet Mask
Serial Remote Control
Arguments
for Command
(Note that all arguments are ASCII numeric codes from 48 to 57)
or Query
1 byte Command or Query.
Sets or returns the NP Module's BPM (Bridge Point-to-Multipoint)
mode in the form a, where:
0 = Off
1 = On
Example: <0001/BRT=0{CR}
NOTE: Changing the Bridge Mode will leave QOS On. QOS should
be turned Off prior to setting the Bridge Mode.
1 byte Command or Query.
Sets or returns the NP Module Router Working Mode in the form a,
where:
1 = Vipersat Hub
2 = Vipersat Hub Expansion
3 = Vipersat Remote
4 = Vipersat Remote Expansion
5 = Multipoint Hub
6 = Multipoint Remote
7 = Point to Point
8 = GigaBit Bridge
Example: <0001/GBM=7{CR}
18 bytes Command or Query.
Sets or returns the Management IP Address and Subnet Mask for the
NP Module in the form aaa.bbb.ccc.ddd.ee, where:
aaa.bbb.ccc.ddd = IP Address, and
ee = Subnet Mask (0-31)
Example: <0001/MIP=010.006.030.001.24{CR}
Description of Arguments
10–61
SLM-5650A Satellite Modem
Revision 10
Target-to-Controller
Response to Query
Response to
(see Description of
Command
Arguments)
BRT= BRT=a
BRT?
BRT*
BRT#
GBM= GBM=a
GBM?
GBM*
GBM#
MIP= MIP=aaa.bbb.ccc.ddd.
ee
MIP?
MIP*
MIP#
