(UTIL:) Firmware  Information  Bootrom
Bootrom:
FW-0000029-
This screen displays the Bootrom release date, the Firmware number and the revision
number. Press [ENT] or [CLR] to return to the previous menu.
(UTIL:) Firmware  Information  Image#X
Image#X: Bulk App M&C Mod Demod Decoder
Filters TxIntfc RxIntfc Turbo
Where Image #X denotes selection of Image#1 or Image#2:
This information may differ for each firmware image load. Both Image screens display
similar information – the loaded image's firmware number with revision letter (shown as 'x');
the firmware version's release date (shown as MM/DD/YY); and the firmware version
number (shown as #.#.#):
Image#X Item
Bulk
App
M&C
Mod
Demod
Decoder
Filters
TxIntfc
RxIntfc
Turbo
Opt
(UTIL:) Firmware  Select
Current Active Image#2
Next Reboot Image#1 #2
This menu sets which Firmware Image loads upon bootup. Use the  arrow keys to
select the Next Reboot Image as #1 or #2. Press [ENT].
Front Panel Operation
10/18/07
1.1.1
(The bulk is the sum of all the individual pieces)
FW-0000030x, MM/DD/YY, #.#.#
FW-0000031x, MM/DD/YY, #.#.#
FW-0000032x, MM/DD/YY, #.#.#
FW-0000033x, MM/DD/YY, #.#.#
FW-0000034x, MM/DD/YY, #.#.#
FW-0000038x, MM/DD/YY, #.#.#
FW-0000034x, MM/DD/YY, #.#.#
FW-0000040x, MM/DD/YY, #.#.#
FW-0000041x, MM/DD/YY, #.#.#
FW-0000042x, MM/DD/YY, #.#.#
This number varies depending on the installed optional interface (NP, GBEI, etc.):
FW-#######x, MM/DD/YY, #.#.#
To reboot the modem with the selected Next Reboot Image, cycle
the power.
