Comtech EF Data SLM-5650A Installation And Operation Manual page 208

Controller-to-Target
Instruction Code and
Qualifier
Parameter
Type
Command Query
Tx Data Rate TDR= TDR?
Insert Tx BERT BEI= N/A
Error
Tx BERT State BTX= BTX?
Tx SCT SCT= SCT?
Reference
Tx BPSK Data TBO= TBO?
Ordering
Tx Clock Invert TCI= TCI?
Serial Remote Control
Arguments
for Command
(Note that all arguments are ASCII numeric codes from 48 to 57)
or Query
10 bytes Command or Query.
Sets or returns the Tx Data Rate in the form xxxxxx.xxx, where:
xxxxxx.xxx = rate in kbps, in 1 bps steps.
Example: <0001/TDR=002047.999{CR} (selects 2047.999 kbps)
None Command only.
Inserts a single bit error in Tx BERT.
Note: This command takes no arguments.
1 byte Command or Query.
Sets or returns the Tx BERT State in the form x, where:
0 = Off
1 = On
Example: <0001/BTX=1{CR} (Tx BERT On)
1 byte Command or Query.
Sets or returns the SCT Clock Reference in the form x, where:
0 = Internal
1 = Data Source Synchronized
2 = Loop Timing (Rx-Satellite Clock)
Example: <0001/SCT=0{CR} (selects Internal Modem Reference)
1 byte Command or Query.
Sets or returns the Invert Transmit BPSK Data Ordering in the form x,
where::
0 = Standard
1 = Non-Standard
Example: <0001/TBO=1{CR} (selects Inverted BPSK Ordering)
1 byte Command or Query.
Sets or returns the Invert Transmit Clock in the form x, where:
0 = Normal
1 = Inverted
Example: <0001/TCI=1{CR} (selects Inverted TX Clock)
Description of Arguments
10–14
SLM-5650A Satellite Modem
Revision 10
Target-to-Controller
Response to Query
Response to
(see Description of
Command
Arguments)
TDR= TDR=xxxxxx.xxx
TDR?
TDR*
TDR#
BEI= N/A
BEI?
BEI*
BEI#
BTX= BTX=x
BTX?
BTX*
BTX#
SCT = SCT=x
SCT?
SCT*
SCT#
TBO = TBO=x
TBO?
TBO*
TBO#
TCI = TCI=x
TCI?
TCI*
TCI#
MN-SLM-5650A
