E.7.5.7.2 Stats | Ethernet Rx
Clear/Refresh Ethernet Rx Stats
Click [Clear] to delete all Ethernet Rx statistics (this will also clear all Ethernet Tx statistics). Click
[Refresh] to update the page with the most recent statistics.
Rx Valid Frames
Column
Port
Unicast
Broadcast
Multicast
Pause
Appendix E
Figure E-31. Stats | Ethernet Rx Statistics Page
This is the corresponding Ethernet port on the NP Interface and, when in BPM Mode, the
Base Modem's J5 Ethernet port.
This is the number of valid Unicast frames received.
This is the number of valid broadcast frames received.
This is the number of valid multicast frames received.
This is the number of PAUSE frames received.
