E.7.5.3.4 Modem | Stats (Modem Statistics Log)
Clear/Refresh Modem Statistics
Click [Clear] to delete all log entries. Click [Refresh] to refresh the Link Statistics Log to display the
most recent entries.
Logging Interval
Use the drop-down list to set the statistics recording interval. Valid settings are from every 10
Minutes to every 90 Minutes in 10-minute increments, or Disabled.
Click [Submit] to save all changes made to this page.
Link Statistics Log
Displays the following read-only modem statistics:
Column
Index
Min Eb/No
Avg Eb/No
Date
Time
Appendix E
Figure E-19. Modem | Stats (Modem Statistics Log) Page
Displays the internal table index.
Minimum measured E /N
b
Average measured E /N
b
Date of the log entry (in YY/MM/DD format).
Time of the log entry (in HH:MM:SS format).
E–37
Description
during the configured time interval.
0
during the configured time interval.
0
