R-S Code
Modulation Type
OQPSK 1/1
OQPSK 1/2
OQPSK 3/4
OQPSK 7/8
8-PSK 2/3
8-PSK 5/6
BPSK 1/2
BPSK 1/2
BPSK 1/2
BPSK 1/2
BPSK 3/4
BPSK 3/4
BPSK 3/4
BPSK 3/4
BPSK 7/8
BPSK 7/8
BPSK 7/8
BPSK 7/8
QPSK 1/2
QPSK 1/2
QPSK 1/2
QPSK 1/2
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
OQPSK 1/2
OQPSK 1/2
OQPSK 1/2
OQPSK 1/2
OQPSK 3/4
OQPSK 3/4
OQPSK 3/4
Appendix B
R-S Depth
Word
Off N/A
Off N/A
Off N/A
Off N/A
Off N/A
Off N/A
126,112 4, 8
219,201 4, 8
225,205 4, 8
220,200 4, 8
126,112 4, 8
219,201 4, 8
225,205 4, 8
220,200 4, 8
126,112 4, 8
219,201 4, 8
225,205 4, 8
220,200 4, 8
126,112 4, 8
219,201 4, 8
225,205 4, 8
220,200 4, 8
126,112 4, 8
219,201 4, 8
225,205 4, 8
220,200 4, 8
126,112 4, 8
219,201 4, 8
225,205 4, 8
220,200 4, 8
126,112 4, 8
219,201 4, 8
225,205 4, 8
220,200 4, 8
126,112 4, 8
219,201 4, 8
225,205 4, 8
Data Rate (kbps)
Min Max
64 20000
64 30000
64 45000
64 51840
256 51840
256 51840
64 13333.333
64 13767.123
64 13666.666
64 13636.363
64 20000
64 20650.684
64 20500
64 20454.545
64 23333.333
64 24092.465
64 23916.666
64 23863.636
64 26666.666
64 27534.246
64 27333.333
64 27272.727
64 40000
64 41301.369
64 41000
64 40909.090
64 46666.666
64 48184.931
64 47833.333
64 47727.272
64 26666.666
64 27534.246
64 27333.333
64 27272.727
64 40000
64 41301.369
64 41000
B–3
SLM-5650A Satellite Modem
Revision 10
Symbol Rate (ksps)
Min Max
32 10000
64 30000
42.666 30000
36.571 29622.857
128 25920
102.4 20736
144 29999.999
139.462 29999.999
140.487 29999.998
140.8 30000
96 29999.999
92.975 29999.998
93.658 29999.999
93.867 29999.999
82.826 30000
79.692 29999.999
80.278 29999.999
80.457 30000
72 29999.999
69.371 29999.999
70.243 29999.999
70.4 30000
48 30000
46.487 29999.999
46.829 30000
46.933 30000
41.143 30000
39.846 29999.999
40.139 29999.999
40.229 30000
72 29999.999
69.371 29999.999
70.243 29999.999
70.4 30000
48 30000
46.487 29999.999
46.829 30000
