D.4.3 LVDS Interface Module Removal and Installation
WARNING!
Make sure that the unit is POWERED OFF. Serious injury or damage to the
equipment could result if the unit is powered during module removal or
installation! You must take care not to damage the module's components
during removal or installation.
D.4.3.1 LVDS Interface Module Removal Procedure
Step
1 Turn off the power to the modem.
2 Disconnect all cable (DB-25) from the Interface Module.
3 Loosen the (two) captive screws securing the module to the chassis.
4 Pull the module straight out until it is clear of the chassis slot.
Appendix D
Figure D-10. LVDS Interface Module Removal or Installation
Task
