E.4 NP Interface Module Removal and Installation
Ensure that the unit is POWERED OFF. Serious injury or damage to the
equipment could result if the unit is powered during module removal or
installation. You must take care not to damage the module's components
during removal or installation.
E.4.1 NP Interface Module Removal
Step
1 Turn off the power to the modem.
2
Disconnect the RJ-45 cable from the NP Interface Module.
3 Loosen the (two) captive screws securing the module to the chassis.
4
Pull the module straight out until it is clear of the chassis slot.
E.4.2 NP Interface Module Installation
Step
1 Insert the NP Interface Module straight into the slot, using the chassis' internal card guides, until it
plugs securely into the internal card receptacle.
2 Secure the module to the chassis using the (two) captive screws.
3
Connect the RJ-45 cable to the NP Interface Module.
4 Turn on the power to the modem.
Appendix E
Figure E-3. NP Interface Module Removal or Installation
