10.3 Remote Commands and Queries

Typical for all tables, see Section 10.2.4.5 for the use of Instruction Code Qualifiers in Controller-to-Target ("Command"
or "Query") and Target-to-Controller ("Response to Command") communications.
Shaded, bold entries indicate PRIORITY commands/queries. Any change to a higher priority parameter can override any
of the lower priority parameters. See the note provided at the beginning of each section for specific details.
10.3.1 Table Indexes
NOTES:
1) Index Columns – Where Column 'C'=Command, and Column 'Q'=Query, columns marked 'X' designate the instruction code as
Command only, Query only, or Command or Query. Where CODE=XXX, this indicates a priority command.
2) In the tables that follow, the following codes are used in the 'Response to Command' column (per Sect. 8.5.5):
= Message ok
? Received ok, but invalid arguments were found.
^ Message ok, but unit is in Ethernet mode.
Section 10.3.2
CODE C Q PAGE
MOM X X 10–10
Serial Remote Control
Initial Setup – Priority Commands and Queries
CODE C Q PAGE
ITF X X 10–11
# Message ok, but unit is not in Remote mode.
~ Time out of a pass-through message, either to via EDMAC or to a local
ODU.
CODE C Q PAGE
RFB X X 10–10
10–7
