Show the Running-Config for the Demand Interface

To check your demand routing configuration, you must view the running-
config file. From the enable mode context, enter:
ProCurve# show running-config
You must then scroll through the file to find the various commands you entered
for demand routing.
To view the configuration of just the demand interface, enter:
ProCurve# show running-config interface demand <number>
Figure 3-26 shows the running-config for a demand interface that is configured
to use MLPPP and PPP authentication.
interface demand 1
idle-timeout 240
resource pool Pool
match-interesting list Call out
match-interesting reverse list Call in
connect-sequence 1 dial-string 9633333 forced-isdn-64k busyout-threshold 3
connect-sequence 2 dial-string 9634444 forced-isdn-64k busyout-threshold 3
connect-sequence interface-recovery retry-interval 120 max-retries 0
ip address 10.1.1.1
ppp authentication pap
username procurve password procurve
ppp pap sent-username procurve password procurve
no shutdown
Figure 3-26. Viewing the Running-Config for a Demand Interface
After you configure demand routing, you should test your configuration to
ensure that it is working correctly. Is the right traffic triggering the connection,
and can the backup interface successfully establish a connection to the far-
end router? Are your settings for the idle-timeout and the fast-idle sufficient
for your WAN environment?

Checking the Demand Interface

The first step you should take to check your configuration is also the first step
you should take to troubleshoot demand routing. You should ensure that the
demand interface is up, has a valid IP address and connect sequence. You
should also ensure that the associated BRI or modem interfaces are ready to
Viewing Backup Configurations and Troubleshooting Backup Connections
255.255.255.0

Troubleshooting Demand Routing

Configuring Backup WAN Connections
3-79
