AS 2
.2
ISP 2
10.2.0.0 /24
Figure 13-20. Example BGP Configuration

Example 1: Baseline BGP Configuration

A baseline configuration allows Router A to:
connect to BGP neighbors—in this example, the ISP routers
advertise the local network to all neighbors
receive all routes that neighbors advertise to it
Complete these steps to configure the ProCurve Secure Router:
1. Configure router interfaces. Router A connects to the ISPs using PPPoE
over ADSL. See Figure 13-21 for the running-config for the connections.
IP Routing—Configuring RIP, OSPF, BGP, and PBR
AS 1
10.1.1.0 /24
Network 1
.3
.1
.3
RouterA
10.1.0.0 /24
AS 3
Configuring BGP
Customer
ISP 1
13-107
