Adding Remote Ids - HP ProCurve Secure Router 7203 dl Advanced Management And Configuration Manual

Using the Web Browser Interface for Advanced Configuration Tasks
Setting Up Virtual Private Networks
14-90
4. If IKE will refer to a RADIUS server for VPN peers' passwords, you must
configure the router to communicate with this server. See "Configuring
Authentication Using a RADIUS Server" on page 14-28 of the Basic
Management and Configuration Guide.
5. Click Apply.
6. Select VPN Peers under VPN in the left navigation bar.
7. Move to the Create VPN Peers window. In the Modify/View/Delete Peer
section, click the name of the peer that should require Xauth. The win-
dows for the steps to configure this peer display.
8. Move to the IKE Configuration section of the Step 1 window.
Figure 14-66. Enabling Xauth
9. Choose the Xauth method from Xauth Enabled pull-down menu:
a. To use the router's username and password database, select Local
Userlist.
b. To use a RADIUS server database, select Radius Server.

Adding Remote IDs

The remote ID list acts as a username database for the VPN. The ID type can
be an IP address or network, domain name, email address, or ASN distin-
guished name. If you are using preshared keys for authentication, you can
associate a preshared key with the remote ID, much as you would a password
with a username.
You should add an entry for each peer to which the router will make a VPN
connection as you configure the connection. However, you can also add an
entry in the VPN Peers window. You can also delete misconfigured entries.
