STEP # 2 USING AN ADJUSTMENT WRENCH PLACED AS SHOWN IN PICTURE.
TIGHTEN B E L T
TOAON
BORROUGHS GAGE. #BT-3395-ACB.
STEP #3 TIGHTEN BOLT (
#
1 ) TO 20-35 L B . FT.
STEP # 4 TIGHTEN BOLTS (#2) (#3) (#4) (#5)
6
( # 6 ) TO 20-35 10. FT.
W/F FIREBIRD
AIR CONDITIONING
WIRE & WASHER COMPRESSOR
B E L T THICKNESS
PONTIAC TEMPEST COMPRESSOR
Fig. 1A-66 Typical Compressor Installation V.8
Models
