Micromeritics Elzone II 5390 Operator's Manual page 78

Elzone II 5390 Confirm
3. Click Export
4. Access the Export directory to retrieve the exported file(s).
Converting Sample Files
The Convert function enables you to convert two different file types to a format
compatible with the current Elzone program.
• Elzone: copies and converts data from sample files used with the Model 5380
Series of analyzers
• ASCII: copies and converts data from a text file
Regardless of which type of file you are converting, it must first be copied into the Import
directory so that it will appear in the Convert dialog.
Elzone Files
1. Select File > Convert > Elzone; the Convert Elzone Dialog is displayed.
2. In the Destination group box, choose the directory(ies) into which the file is to be
saved.
3-42
; the file is exported automatically to the export directory.
Converting Sample Files
539-42822-01 (Rev B) - Nov 2017
