Appendix F
F. CONCENTRATION ANALYSES
Concentration analyses are performed when you need to determine the concentration of
particles within your sample.
You must have the volumetric pump installed to perform concentration analyses.
Standard Analysis
Creating the Sample File
These instructions are given for the Developer's (Advanced) format. If an Analyst is to
create the file, appropriate templates will have to be created by the Developer.
1. Select File > New > Sample Information; the Create a Sample File dialog
containing templates is displayed.
2. Choose a template, the click
3. On the Sample Information dialog:
a. Enter an appropriate description in the Sample field.
b. Ensure that Automatically collected is selected as the type of data.
c. Enter the dilution factor for the sample you are analyzing. Refer to Preparing
the Sample on the next page for determining this value.
d. Enter information in any other fields as desired (Operator, Submitter, etc.).
4. Click the Analysis Conditions tab, then:
a. Click the down arrow to the right of the Orifice Tube field and choose the orifice
tube you plan to use.
b. Select Specify Diameter range, then enter a range in the Minimum and
Maximum fields.
c. Click
Rate and enter the appropriate flow rate for the orifice tube being used. (Refer to
Table 3-1. Particle Concentration
OK
539-42822-01 (Rev A) - Nov 2017
Create
Flow Control to display the Flow Control dialog. Select Volumetric Flow
to return to the Analysis Conditions dialog.
; the Sample Information dialog is displayed.
Guidelines, page 3-33
Elzone II 5390 Confirm
for guidelines.) Click
F-1
