Elzone II 5390 Confirm
Show report title
Show graphic
Test
Reference
4-26
Select this option to have a title appear at the top of your
report; use the adjacent field to enter the text.
You can enter up to 40 characters.
Select this option to have a graphic (bitmap or enhanced
metafile) display above the report title. For example, you
may wish to display your company logo. Click
to select the desired graphic, then use the Height and
Width fields to specify the size. This image can be edited
from the report window.
Use this drop-down list to choose the test on which to
report data. You can report data from the first test, the last
test, an average of all tests, or on all tests.
For background files, the test selected in this field is the
one that will be used for any background operation; for
example if you have selected this file to use for subtract-
ing a background.
Displays the Reference Sample dialog so that you can
specify a sample file with which to compare analysis
results of the current sample; produces a Difference of
Reference report.
Click to display the Reference Sample File
Browse
Selection dialog containing a list of sample files from
which to choose a file.
Use Clear to clear a field of its entry.
Browse
