Elzone II 5390 Confirm
Analysis Conditions
Analysis conditions specify the data used to guide an analysis.
Analysis
Refer to
dialogs used in this procedure.
Perform the following steps to create an analysis conditions file:
1. Select File >New > Analysis conditions; the Create an Analysis Conditions File
dialog containing the available templates is displayed.
2. Choose a template then click
3. Enter a description in the Analysis Conditions field. Be sure to use an intuitive
description so that you can recognize it easily. You can use up to 40 characters in this
field.
Use Replace to copy values of an existing file into the current one. You can edit the
values after they have been copied into the file if desired. This is useful when you
have an existing file that contains many of the values that you wish to use in the
current file.
4. Choose an appropriate orifice tube from the Orifice Tube drop-down list. If the tube
you select is preceded with an asterisk, the tube has not been calibrated for the current
instrument.
If the tube you plan to use is not included in the list, use the
it.
3-4
Conditions, page 4-12
if you need clarification of the fields on the
Create ; the Analysis Conditions dialog is displayed:
Creating Parameter Files
Add push button to add
