Micromeritics Elzone II 5390 Operator's Manual page 135

New
Entered Data
An Entered Data tab displays when you select Manually entered on the Sample
information dialog. The dialog for Entered Data enables you to enter data as opposed to
having it collected automatically during analysis.
Use this key
sequence to
add rows to the
list.
You cannot enter data if you are using a computer other than the one that is connected to
the analyzer.
Table
Insert
Delete
Clear
Size Type
Distribution Type
539-42822-01 (Rev B) - Nov 2017
Enables you to enter the desired data; data are entered in
an ascending order.
Inserts a row above the selected row.
Deletes the selected row.
Clears the table of all entries but two; two are required.
Enables you to select the type of size data you plan to
enter; you can enter particle size or sieve size data.
Enables you to select the type of distribution for the data
you plan to enter.
Elzone II 5390 Confirm
4-47
