Elzone II 5390 Confirm
X- and Y-Axes 
Variable fields
Axis Range
Autoscale
Recalculate archived SPC
results
Tabular report
Label data
Samples
6-12
Allows you to designate the X- and Y-axes variables.
Click on the down arrow to display a list of variables. The
variables in this list are the ones you specified in the SPC
report options.
With this option, you can plot the regression of up to
three Y-axis variables against the X-axis variable. The X-
axis specifies the independent variable for the regression,
while the Y-axes provide the dependent variables.
Enables you to specify the beginning and ending values
for the X- and Y-axis ranges. Data collected outside these
ranges are not included in the plot. These fields are dis-
abled if you choose Autoscale.
Allows you to have the X- and/or Y-axes scaled automat-
ically. When scaled automatically, both axes begin at
zero. The analysis program uses the highest values col-
lected during analysis as the ending points.
Select this option to have archived SPC values recalcu-
lated. This ensures that any changes made to the SPC
Report Options are included in the new report; however,
it does lengthen the time required to generate the report.
Enables you to generate tabular, as well as graphical, data
of the included samples. A tabular report contains the
numeric values contributed by each sample.
Allows you to label the points on the plot to correspond
with the values in the sample files.
Displays the Regression Report Sample Selection dialog,
allowing you to choose the sample files you wish to have
reported.
Regression Report
