Micromeritics Elzone II 5390 Operator's Manual page 171

Sample Analysis
From Graph
Save Settings
Actions
Ending Conditions
Time, Volume, Total and
Modal count
539-42822-01 (Rev A) - Nov 2017
This option enables you to choose a size range marked on
the graph by a set of cross hairs. This button does not
become enabled until you have marked the range.
Simply click in the graph at the point you wish to begin
the range to place the first cross hair. Hold down the
key and click at the ending range to place the second
cross hair. Then click From Graph
The total number of particles in the specified range dis-
plays in the lower left of the dialog.
Refer to page 4-17 if you need assistance on this dialog.
Displays the Save as Analysis Conditions dialog allow-
ing you to save the current settings as an Analysis condi-
tions file.
Disabled for an Analyst.
The following actions are available prior to analysis:
• Drain : drains the system, leaving the glassware empty
• : fills the glassware with electrolyte solution
Fill
• : flushes solution through the glassware; it does
Flush
not empty the glassware
• : displays the Rinse dialog enabling you to spec-
Rinse
ify rinsing preferences
• : clears any blockage that may be in
Clear Blockage
the orifice tube. This option is also available during
analysis, but only up to the point where data collection
begins.
• : turns the stirrer off.
Turn Stirrer Off
Displays the Ending Condition dialog so that you can edit
the ending criteria if desired.
Disabled for an Analyst.
Displays the parameters for the current ending condi-
tions.
Elzone II 5390 Confirm
Shift
to set the range.
5-11
