Micromeritics Elzone II 5390 Operator's Manual page 129

New
Autoscale
Options Report
The Options report is a subset of the contents report; it provides pertinent information for
the following:
• the sample
• analysis conditions
• material properties
• data collection
The Options Report cannot be edited.
Calibration Report
The Orifice Tube Calibration report contains tabular data for the reference material and
goodness of fit, as well as a graphical representation of the goodness of fit. This report
can also be generated using the Orifice Tube Calibration command on the Reports menu;
refer to Orifice Tube
The Calibration Report cannot be edited.
Sample Log Report
The Sample Log Report provides the following statistics:
• manual control operations performed during analysis
• Information entered using the
• warnings and/or errors that occurred during analysis
The Sample Log Report cannot be edited.
539-42822-01 (Rev B) - Nov 2017
Select this option to have the X- and/or Y-axis scaled
automatically. Both axes begin at zero; the highest values
collected during analysis are the ending points.
If you deselect this option, the adjacent fields become
enabled so that you may specify a range. Valid ranges are
displayed in the information bar when the field is
selected.
Calibration, page 6-7 for additional information on this report.
Add Log Entry
Elzone II 5390 Confirm
push button on the sample file editor
4-41
