Editing Tables
Select a table to edit; a dialog similar to this one is displayed.
The title bar
displays the
name of the
table being
edited.
The Standard Class Size Table and the Standard Sieve Table are fixed and, therefore, do
not contain a table of values, nor push buttons.
• The Standard Class Size Table is fixed based on the classes specified in Analysis
conditions (Data Setup). After the analysis is finished, data can be edited from the
Collected Data dialog.
• The Standard Sieve Table is fixed based on the sieves specified using the Data
presentation, Sieve Table option on the Options menu.
Table
539-42822-01 (Rev B) - Nov 2017
The table and editing push buttons do not display
if you are editing the Standard Class Size or
Standard Sieve Table.
Included only on the Cumulative
Fraction Table dialog.
Enter the values at which you wish the data to be reported
(or accept the defaults).
Not included on the dialogs for the Standard Class Size
Table and the Standard Sieve Table.
Elzone II 5390 Confirm
4-33
