Elzone II 5390 Confirm
Orifice Tubes
A wide range of orifice tubes is available to accommodate many sample sizes. The orifice
is drilled in a synthetic jewel which is permanently sealed into the wall of the tube. Each
tube is carefully tested, using standard samples of monodispersed polymer spheres, to
verify it produces distortion-free measurements. The effective range of particle sizes a
typical orifice can measure is from 2% to 60% of its orifice diameter. You can blend
(merge) data obtained from multiple orifice tubes to report a continuous distribution for
overlapping segments of a broad range of particle sizes.
Analysis Program
The Elzone analysis program is operated in a Windows environment, and includes wiz-
ards and intuitive screens enabling you to perform system operations quickly and
efficiently.
Also included is a report system which allows you to manipulate and customize reports.
You can zoom in on portions of the graphs or shift the axes to examine fine details. Scal-
able graphs can be copied to the clipboard and pasted into other applications. Reports can
be customized with your choice of fonts and a company logo added to the report header
for an impressive presentation. Refer to
options.
Camera
An optional camera is offered for capturing and displaying pictures of the orifice jewel on
the computer screen. This camera enables you to:
• view particle activity in the orifice
• detect blockages in the orifice
• check the orifice jewel for cracking
• check the orifice for particle build-up
Refer to Ordering Information on page
operating instructions for the camera are located in Appendix H.
1-6
Onscreen Reports, page
9-1 for ordering information. Installation and
539-42822-01 (Rev B) - Nov 2017
System Description
6-22 for available
