Elzone II 5390 Confirm
23. Be sure that only the reference materials to be used in this calibration are selected
(preceded with a check mark). Double-click on a reference material to place (or
remove) a check mark.
24. Verify that the appropriate Electrolyte Solution is listed and selected. If it is not
listed, enter the appropriate information in the Description, Density, and Viscosity
fields and click
25. Click Next
displays data as collected.
If this is a new tube or if the previous orifice tube was different, error message
6116 will display; click No to close the message.
26. When the progress bar reaches 100%, click
previous step shows the
calibration is complete.)
3-24
Add.
to display the Calibrate Orifice Screen, then click
push button disabled; it becomes enabled when the
Save
Calibrating an Orifice Tube
Start ; this screen
Progress Bar
. (The example shown in the
Save
539-42822-01 (Rev B) - Nov 2017
Becomes enabled
when calibration is
complete.
