Elzone II 5390 Confirm
Performing an Analysis
Before you start your analysis, be sure you have:
3 cleaned and calibrated your orifice tube; page
3 filled your supply container with filtered electrolyte; page
3 emptied your waste container
3 optimized instrument settings for the current electrolyte (this also can be done on
the second view of the Sample Analysis dialog before you begin your analysis);
page
3 created your sample file using appropriate analysis conditions (this also can be
done from the Sample Analysis dialog); page 3-10)
If your application is noise-sensitive, read the discussion in Appendix H, page
guidelines in obtaining optimum performance from your elzone.
1. Select Unit > Sample Analysis; the Sample Analysis dialog is displayed.
2. Click
Browse
3. Select your file, then click
parameters in the file you selected.
3-36
3-31
; the Select a File for Analysis dialog is displayed.
OK; the Sample Analysis dialog now contains all the
Performing an Analysis
3-52
3-28
539-42822-01 (Rev B) - Nov 2017
H-1 for
