Configuring the ACFP Server (Switch)

Enabling the ACFP Server

Follow these steps to enable the ACFP server:
To do...
Enter system view
Enable the ACFP server

Enabling the ACFP Trap Function

To make ACFP work normally, you must enable the device to send traps of the ACFP module.
After the trap function on the ACFP module is enabled, the ACFP module will generate traps to report
important events of the module. The levels of the ACFP traps are described in
Table 1-1 ACFP trap message level
Context ID type changed
ACFP client registration
ACFP client deregistration
ACSEI detects that ACFP client had no response
ACFP server does not support the working mode of the ACFP
client
Expiration period of ACFP collaboration policy changed
ACFP collaboration rules are created
ACFP collaboration rules are removed
ACFP collaboration rules failed
Expiration period of ACFP collaboration policy timed out
The generated traps will be sent to the information center of the device. With the parameters for the
information center set, the output rules for traps (that is, whether the traps are allowed to be output and
the output destinations) are decided. For the configuration of the parameters for the information center,
refer to Information Center Configuration in the System Volume.
Follow these steps to enable the ACFP trap function:
To do...
Enter system view
Enable the trap function of the
ACFP module
Use the command...
system-view
acfp server enable
Trap message
Use the command...
system-view
snmp-agent trap enable acfp
[ client | policy | rule | server ]
1-6
Remarks
—
Required
Disabled by default
Table 1-1.
Level
notifications
notifications
notifications
warnings
errors
notifications
informational
informational
errors
notifications
Remarks
—
Optional
Enabled by default
