Configuration procedure
# Create a DLSw test group and configure related test parameters.
<DeviceA> system-view
[DeviceA] nqa entry admin test
[DeviceA-nqa-admin-test] type dlsw
[DeviceA-nqa-admin-test-dlsw] destination ip 10.2.2.2
# Enable the saving of history records.
[DeviceA-nqa-admin-test-dlsw] history-record enable
[DeviceA-nqa-admin-test-dlsw] quit
# Enable DLSw test.
[DeviceA] nqa schedule admin test start-time now lifetime forever
# Disable DLSw test after the test begins for a period of time.
[DeviceA] undo nqa schedule admin test
# Display the result of the last DLSw test.
[DeviceA] display nqa result admin test
NQA entry(admin admin, tag test) test results:
Destination IP address: 10.2.2.2
Send operation times: 1
Min/Max/Average round trip time: 19/19/19
Square-Sum of round trip time: 361
Last succeeded probe time: 2007-11-22 10:40:27.7
Extended results:
Packet lost in test: 0%
Failures due to timeout: 0
Failures due to disconnect: 0
Failures due to no connection: 0
Failures due to sequence error: 0
Failures due to internal error: 0
Failures due to other errors: 0
Packet(s) arrived late: 0
# Display the history of DLSw tests.
[DeviceA] display nqa history admin test
NQA entry(admin admin, tag test) history record(s):
Index
1

NQA Collaboration Configuration Example

Network requirements
As shown in Figure
Associate the static route, track entry, and NQA test group to verify static route configuration in real time.
Response Status
19 Succeeded
1-14, configure a static route to Switch C on Switch A, with Switch B as the next hop.
Receive response times: 1
Time
2007-11-22 10:40:27.7
1-40
