Actual frequency: 100.0000 Hz
Clock precision: 2^18
Clock offset: 0.0000 ms
Root delay: 31.00 ms
Root dispersion: 8.31 ms
Peer dispersion: 34.30 ms
Reference time: 16:01:51.713 UTC Sep 19 2005 (C6D95F6F.B6872B02)
As shown above, Switch D has been synchronized to Switch C, and the clock stratum level of Switch D
is 3, while that of Switch C is 2.
# View the NTP session information of Switch D, which shows that an association has been set up
between Switch D and Switch C.
[SwitchD-Vlan-interface2] display ntp-service sessions
source
**************************************************************************
[1234] 3.0.1.31
note: 1 source(master),2 source(peer),3 selected,4 candidate,5 configured
Total associations :

Configuring NTP Multicast Mode

Network requirements
Switch C's local clock is to be used as a reference source, with the stratum level of 2.
Switch C works in the multicast server mode and sends out multicast messages from
VLAN-interface 2.
Switch A and Switch D work in the multicast client mode and receive multicast messages through
VLAN-interface 3 and VLAN-interface 2 respectively.
Figure 1-10 Network diagram for NTP multicast mode configuration
Vlan-int3
1.0.1.11/24
Switch A
Configuration procedure
1) Configuration on Switch C:
# Specify the local clock as the reference source, with the stratum level of 2.
<SwitchC> system-view
[SwitchC] ntp-service refclock-master 2
reference stra reach
127.127.1.0 2 254
1
Vlan-int3 Vlan-int2
1.0.1.10/24 3.0.1.30/24
Switch B
poll now offset
64 62 -16.0
Vlan-int2
3.0.1.31/24
Switch C
Vlan-int2
3.0.1.32/24
Switch D
1-21
delay disper
32.0 16.6
