Configuration procedure
Prior to performing the following configuration, be sure you have completed MPLS VPN-related
configurations and make sure of the reachability between CE 1 and PE 1, between PE 1 and PE 2, and
between PE 2 and CE 3. Refer to the MPLS Volume to configure MPLS VPN.
1) Configuration on CE 1:
# Specify the local clock as the reference source, with the stratum level of 1.
<CE1> system-view
[CE1] ntp-service refclcok-master 1
2) Configuration on CE 3:
# Specify CE 1 in VPN 1 as the NTP server of CE 3.
<CE3> system-view
[CE3] ntp-service unicast-server 10.1.1.1
# View the NTP session information and status information on CE 3 a certain period of time later. The
information should show that CE 3 has been synchronized to CE 1, with the clock stratum level of 2.
[CE3] display ntp-service status
Clock status: synchronized
Clock stratum: 2
Reference clock ID: 10.1.1.1
Nominal frequency: 99.9100 Hz
Actual frequency: 99.9100 Hz
Clock precision: 2^18
Clock offset: 0.0000 ms
Root delay: 47.00 ms
Root dispersion: 0.18 ms
Peer dispersion: 34.29 ms
Reference time: 02:36:23.119 UTC Jan 1 2001(BDFA6BA7.1E76C8B4)
[CE3] display ntp-service sessions
source reference
**************************************************************************
[12345]10.1.1.1
note: 1 source(master),2 source(peer),3 selected,4 candidate,5 configured
Total associations :
[CE3] display ntp-service trace
server 127.0.0.1,stratum 2, offset -0.013500, synch distance 0.03154
server 10.1.1.1,stratum 1, offset -0.506500, synch distance 0.03429
refid 127.127.1.0
stra reach poll
LOCL 1 7
1
1-28
now offset delay disper
64 15 0.0 47.0 7.8
