Step 4: Configure in CODESYS
Double click desktop icon or start CODESYS in menu of START, then operate as below：
1）Create a new project
⚫ In menu bar of CODESYS main page, select "file"→"create new project", then select
"standard project" in pop up dialog and set file name and storage directory.
⚫ After above operations and confirmation, select added CPU file device (MAT-LC-C06_V1.0)
and selected program language in pop up dialog, click "confirm" to finish the project creation.
⚫ In device directory, right click "<blank><blank>" under "CPU Local IO", select "Insert device"
and in pop-up dialog, select supplier as "SMB", select "Local IO" and click "Insert device" button
to add the device, which will be finally displayed under CPU Local IO.
