Pulse Output Module - SMB MAT-LC-C Series User Manual

C.6

Pulse output module

Table C-22 Introduction
Table C-23 HSP-04 specifications
Dimensions
W×H×D
Power supply
Rated input voltage
Input voltage range
Input current
Reverse
protection
Bus power voltage
Bus power current
LED indicator light
Indicator light
Output
Number of output
channels
Output type
Max output frequency
Duty cycle of output
signal
Rated output voltage
Output voltage range
Output signal logic "0" 3.8V（min）
Output signal logic "1" 0.3V（max）
Surge current
Current per point （ max） 20mA
Max current at each
common terminal
Leak current（max）
Isolation
Name
4-ch differential/single-ended signal
HSP-04
output
34×115×101.6 mm
24V DC
20.4V~28.8V DC
100mA
polarity
Yes
+5V DC
100mA
ON：Exists input signal，OFF：No input signal
4
Differential signal
4MHz
-
5VDC
0~5.5VDC
8A，sustain100ms
No
10μA
500VAC，1min
Specifications
123
Part No.
MAT-LC-HSP-04
Single-ended（NPN）signal
500KHz
50%
5~24VDC
5~28.8VDC
0.5V（max）
Vcc~0.5V（min）
20mA
160mA
