SMB MAT-LC-C Series User Manual page 125

Bus power current
LED indicator light
24V power light
（Green）
SF light（Red）
BF light（Red）
LINK light（Green）
(Slave status indicator)
RJ45 light(Green)
Note 1: When the extension bus of the slave has no module of output type, the communication
between the slave and the master is disconnected, and the slave will not switch to safe
operation.
Table C-31 Functions
Type Functions
Codesys
or
Hardware
third party
configuration
configurati
on
I/O
Extension
Extension
Bus
interface
Communication
EtherCAT
interface
Power
Isolation
isolation
Power
Protection
protection
Table C-32 Communication port specifications
EtherCAT communication
Interface
Baud rate
Protocol type
The communication
distance between
1.6A
ON：24VDC power supply is normal，OFF：No 24VDC power supply
ON：EtherCAT slave module failure，OFF：No error
ON: The extension bus is faulty. Off: No error
ON: Normal;Blinking: pre-operation (2), safe operation (4) (see Note
1);OFF: No connection (0), initialization (1)
On: Connects to another EtherCAT interface
Off: No EtherCAT interface is connected
Blinking: The EtherCAT interface is communicating with the EtherCAT
interface
other
The added ETC-00 module supports 8 slot expansion
Supports max 8 expansion modules, only digital module,
analog module and temperature module can be connected
Provides expansion module interface, supports MAT-LC-CXX
PLC custom 55MHZ bus protocol
Supports CANopen over EtherCAT (CoE)
The external power supply is isolated from the system power
supply
The power supply provides reverse connection protection and
surge absorption function
1double RJ45 port
100Mbps
CANopen over EtherCAT (CoE)
Supports PDO
Supports SDO
Supports EtherCAT State machine instructions
Supports the third-party EtherCAT master
100m (100BASE-TX)
