J Ordering Information - SMB MAT-LC-C Series User Manual

J Ordering Information
Table J-1 List of ordering information
LC-C06 Motion Controller
LC-C06 main control module , 32MB program data space, 64KB
power-down retention data , 55M expansion bus, 1 RS485
communication port, MODBUS free port protocol , 1 EtherCAT
interface, 1 EtherNET interface, 1 CAN port, 1 USB ports, support
SoftMotion
LC-C07 Motion Controller
LC-C07 main control module, 32MB program data space, 64KB
power-down retention data, 55M expansion bus, 1 RS485
communication port, MODBUS free port protocol, 1 EtherCAT interface,
1 EtherNET interface, 1 CAN port, 1 USB port, support SoftMotion,
CNC
Power module
PWR-020S1 power module, input 85～264V AC, output 24V DC/2A
High-speed counting module
HSC-02 high-speed counting module, 2-way differential/single-ended
signal input
Pulse output module
HSP-04 pulse output module, 4-channel differential/single-ended signal
output
EtherCAT Slave Module
EtherCAT slave module , up to 8 expansion modules can be attached
Digital I/O
DIT-08 digital module, digital input 8 x 24VDC
DIT-16 digital module, digital input 16 x 24VDC
DQT-08 digital module, digital output 8 x 24VDC
DQT-16 digital module, digital output 16 x 24VDC
DQR-08 digital module, digital output 8 x relay
DQR-16 digital module, digital output 16 x relay
Analog I/O
AIS-04 analog module, analog voltage and current input, 4AI x 12bit
AQS-04 analog module, analog voltage and current output, 4AQ x 12bit
Accessories
PLC lithium battery, voltage 3.6 V , capacity 2700 mAh
Specification description
174
Part Number
MAT-LC-C06
MAT-LC-C07
MAT-PWR-020S1
MAT-LC-HSC-02
MAT-LC-HSP-04
MAT-LC-ETC-00S1
MAT-LC-DIT-08
MAT-LC-DIT-16
MAT-LC-DQT-08
MAT-LC-DQT-16
MAT-LC-DQR-08
MAT-LC-DQR-16
MAT-LC-AIS-04
MAT-LC-AQS-04
MAT-LC-BAT-00S1
