SMB MAT-LC-C Series User Manual page 113

Name
PWR-020S1 power
module
Table C-2 General properties of PWR-020S1 power module
Physical property
Dimensions（W×H×D）
LED Indicator characteristic
24V power indicator
(green)
Switch property
Switch
Table C-3 Function characteristics of PWR-020S1 power module
Characteristics of input voltage
Voltage range
Rated frequency
Frequency range
Efficiency
AC current
Surge current (maximum at
25 ℃)
Leakage current
Characteristics of output voltage
DC voltage / rated current
Rated power
Ripple and noise (maximum)
Voltage output range
Start / rise / hold time
Isolation (power input
output)
Protection
Overload protection
Overvoltage protection
Surge protection
Overcurrent protection
Safety electromagnetic compatibility
Withstand voltage
Isolation resistance
Standards
Specification
Input：85～264V AC
Output：24V DC/2A
34×115×101.6 mm
On: with 24V DC output, OFF: without 24VDC output
Control 24V DC power output
ON：with 24V DC output, OFF：without 24VDC output
85～264VAC, wide voltage input
50Hz/60Hz
47Hz～63Hz
75%
0.9A/110V、0.5A/220V
≤20A/110V、≤35A/220V
≤5mA/220VAC
24VDC/2A
48W
150mVp-p
±5%
≤2.5s/≤50ms/≥20ms
and Isolation between 110V/220V AC and 24V DC
105% ～ 130% of rated output power, cut off output and
utomatic recovery after troubleshooting
115%～135%Ue；Protection mode: hiccup mode, automatic
recovery after troubleshooting
The power supply terminal provides surge absorption function
The power output terminal provides overcurrent protection
Input~output:1.5KVDC,input-PE:1.5KVDC,output-PE:
500VDC
Input~output, input-PE, output-PE: 100MΩ/500VDC
Safety: UL60950 and UL1950, Electromagnetism: EN55022
113
Order No.
MAT-PWR-020S1
