SMB MAT-LC-C Series User Manual page 33

Table 4-5 Definition of 24V DC output power interface of PWR-020S1
4-Position Removable
Terminal
Table 4-6 DIP switch definition of PWR-020S1
Two-state switch
Signal
L+
M
L+
M
Tag number
ON
OFF
33
Signal definition
24Vpower supply positive
24Vpower supply negative
24Vpower supply positive
24Vpower supply negative
Dial direction Signal definition
Up With 24V DC output
Down No 24V DC output
