SMB MAT-LC-C Series User Manual page 117

Rated output 24V DC
voltage
Output voltage 20.4~28.8V DC
range
Logic 1(Min) 20V DC
0.1V DC，10KΩ load
Logic 0(Max)
Output current
0.5A
(Max)
Current at each
Max 4A
common terminal
Output leakage
current 15uA
(maximum)
8A，100ms
Surge current
5W
Lamp load
0.3Ω， Max 0.6Ω
Contact
resistance
Off to on (Max)：50us
Output delay
On to off (Max)：200us
Output frequency
1KHz
(Max)
Mechanical life
-
(without load)
Contact life (rated
-
load)
Isolation 500V AC, duration: 1min
Field to logic -
Coil to contact
Isolation points of
each group
Simultaneous ON
points
Two outputs in
Support parallel connection of two outputs in the same group
parallel
Shield 500m
Cable
Unshie
length 150m
lded
8 8
8 16
117
DC：24V，AC：
110V/220V
DC：5～30V，
AC：5～250V
-
-
2A
Max 16A
-
5A，4s@10%
duty cycle
DC：30W /AC：
200W
Max of new
device 0.2Ω
Max 10ms
Resistive load:
10Hz
Lamp load: 1Hz
Inductive load:
0.5Hz
10，000，000
100，000
500V AC，
duration: 1min
1500V AC，
duration: 1min
8 8
8 16
