In dialog box of Device Repository, open "PLC"→"SoftMotion PLCs" and find installed
"MAT-LC-C06_V1.0"; open "field bus"→"EtherCAT"→"Slave" to find installed "EtherCAT Slave".
After checking, if more device files need to be installed, select "tools"→"Option", tick "enable
Device Repository dialog box".
Hint
1）If you need to use other devices of SMB (CANopen or other EtherCAT slave device),
installation of below device description files will be needed:
CANopen slave device configuration files（*.eds）：SMB_SD_LP_C_V1_XX.eds

EtherCAT slave device configuration files（*.xml）：SMB_SD_LP_E_V1_XX.xml；
2）Please download needed files in SMB website: https://www.smbtechnics.com。
2) Create a new project
⚫ In menu bar of CODESYS main page, select "file"→"create new project", then select
"standard project" in pop up dialog and set file name and storage directory.
⚫ After above operations and confirmation, select added CPU file device (MAT-LC-C06_V1.0)
and selected program language in pop up dialog, click "confirm" to finish the project creation.
