◆ Fast Operation
The bit instruction execution speed of the CPU is 0.015μs/step.
Floating point instruction execution speed is 1µs/step
◆ High-speed Transmission
The high-speed bus between CPU and expansion module adopts M-LVDS technology, and the
data transmission rate reaches 55Mbps. The CPU integrates 10 digital inputs and supports 6
high-speed counters.
◆ Powerful System Expansion Capability
Through ETC-00 expansion, the maximum allowable expansion of 1032 I/O modules (128 ETCs,
each ETC Expandable up to 8 modules).
◆ Supports multiple communication protocols
The CPU natively supports communication protocols such as EtherNET, EtherNET/IP, EtherCAT,
CANopen, and Modbus.
◆ Easy and Fast Programming
Use CODESYS V3.5 SP18 PATCH6 for programming, and the CPU has its own USB port host
device interface.
◆ Perfect Operation Control Function
Supports single-axis motion function, electronic cam and electronic gear function SoftMotion
commands and CNC functions that conform to the PLCopen standard.
◆ Support External Battery
The C06/C07 comes with an external battery port. After the external battery is connected, the
power-down retention time is a typical value of more than 2 years.
Note: The external battery needs to be purchased separately from Hexin (Order No.:
MAT-LC-BAT-00S1). For the installation of the external battery, see 3.4 Installation Method
1.1.2

C06/C07 Series Expansion Modules

C06/C07 motion controller belongs to MAT-LC-CXX series medium-sized PLC family. It can
support MAT-LC-CXX series expansion modules. Its module types include but are not limited to:
digital input and output, analog input and output, high-speed counting, etc. Please refer to the
table below for model numbers:
