4 Power Module

4.1 Specifications

PWR-020S1 power supply module, the best match for MAT-LC-CXX series CPU, can provide
24V DC power supply for CPU and expansion modules (except digital modules). Please select a
power supply module for each rack, and select other power supply for digital input and output
power supply and sensor power supply.
Table 4-1 Basic attributes of the power module PWR-020S1
PWR-020S1 power
Table 4-2 Specifications and Characteristics of Power Module PWR-020S1
Physical Properties
Size（W×H×D）
LED Indicator Characteristics
24V power
(green)
Switching Characteristics
24V DC power control
switch
Input Voltage Characteristics
Voltage range
Rated frequency
Frequency Range
Efficiency
Alternating current
Inrush current (25°C max)
Leakage current
Output Voltage Characteristics
DC voltage/rated current
Rated power
Ripple
(Maximum)
Voltage output range
Start/Rise/Hold Time
Isolation (power input and
output)
Protective function
Overload protection
Overvoltage protection
Surge protection
Name
Input：85~264V AC Output：24V DC/2A
module
34×115×101.6 mm
indicator
On: With 24V DC output, Off: Without 24V DC output
On: With 24V DC output, Off: Without 24V DC output
85~264VAC，Wide voltage input
50Hz/60Hz
47Hz~63Hz
75%
0.9A/110V、0.5A/220V
≤20A/110V、≤35A/220V
≤5mA/220VAC
24VDC/2A
48W
and Noise 150mVp-p
±5%
≤2.5s/≤50ms/≥20ms
Isolation between 110V/220V AC and 24V DC
105%~130% of the rated output power, cut off the output,
automatic recovery after troubleshooting
115%~135%Ue; protection mode: hiccup mode, automatic
recovery after troubleshooting
The power supply side provides surge absorption function
Specifications
31
Order NO.
MAT-PWR-020S1
