Digital Module - SMB MAT-LC-C Series User Manual

Table C-6 Dial switch definition of PWR-020S1
Two-state switch
C.2

Digital module

Table C-7 Basic properties of digital module
DIT-08 digital module
DIT-16 digital module
DQT-08 digital module
DQT-16 digital module
DQR-08 digital module
DQR-16 digital module
Digital input module
Table C-8 Specification of digital input module
Dimensions（W×H×D）
Input points
Current
consumption
Input type
Rated input voltage
Input voltage range
Surge voltage
Logic 1(Min)
Logic 0(Max)
Allowed leakage current of
no.2 connecting wire
proximity switch
sensor(BERO) (Max)
Input filtering
Input frequency
Input impedance
Isolation
Isolation points of each
group
Simultaneous ON points
Cable length
Position
Name
Digital input 8 x 24VDC
Digital input 16 x 24VDC
Digital output 8 x 24VDC
Digital output 16 x 24VDC
Digital output 8 x Relay
Digital output 16 x Relay
Item
34×115×100 mm
24V DC
+5V Bus
Drain type / source type (IEC class 1 drain type)
24V DC，6mA
20.4~28.8V DC
35V DC，duration: 0.5s
15V DC，2.5mA，Flip level: 10.5V DC±15%
5V DC，1mA
1mA
Configurable, support 0.2ms、0.4ms、0.8ms、1.6ms、3.2ms、
6.4ms（default）、12.8ms
1.5KHz，Duty cycle 50%
6.6KΩ
500V AC，duration: 1min
shield 500m
Unshielded 300m
Dial direction
ON Upward
OFF Downward
Specification
DIT-08
8
4mA/channel
60mA
8
8
115
Signal definiton
With 24V DC output
Without 24V DC output
Order No.
MAT-LC-DIT-08
MAT-LC-DIT-16
MAT-LC-DQT-08
MAT-LC-DQT-16
MAT-LC-DQR-08
MAT-LC-DQR-16
DIT-16
16
4mA/ channel
80mA
8
16
