Interface Diagram; Interface Definition - SMB MAT-LC-C Series User Manual

Overcurrent Protection
Safe Electromagnetic Compatibility
Withstand voltage
Isolation resistance
According to the standard
4.2 Wiring Specifications
4.2.1

Interface diagram

4.2.2

Interface definition

Table 4-4 Definition of 220V AC input power interface of PWR-020S1
3-Position Removable
Power output provides overcurrent protection
Input~Output:
500VDC
Input~Output, Input-PE, Output-PE: 100MΩ/500VDC
Safety
compatibility refer to EN55022
Terminal
1.5KVDC, Input-PE:
refer to UL60950
Signal
L
N
32
1.5KVDC, Output-PE:
and UL1950, electromagnetic
Signal definition
Fire Wire
Zero Line
Ground
