Analog Module - SMB MAT-LC-C Series User Manual

C.3

Analog module

Table C-10 Basic properties of analog module
AIS-04 Analog module
AQS-04 Analog module
Table C-11 General properties of analog module
Item
Physical property
Dimensions
（W×H×D）
Power characteristics
Rated
voltage
Input
range
Input current
Polarity
connection
protection
Bus
voltage
Bus
current
LED Indicator characteristics
24VPower
indicator
SF Indicator
C-12 Functional characteristics of analog module
Function
category
Extension
Isolation
Protection
Filtering
Power supply
Name
Analog voltage and current input, 4AI x
12bit
Analog voltage and current output, 4AQ x
12bit
34×115×100 mm
input
24V DC
voltage
20.4V~28.8V DC
65mA
reverse
Yes
supply
+5V DC
supply 50mA
ON: With 24VDC power supply, OFF: without 24VDC power supply
ON: module fault, OFF: normal
Flash: input current signal over limit alarm（only for: 4-20mA）
Function item
Extension
Signal isolation
Power protection
Filtering
Power supply
Specification
AIS-04
Provides bus extension function.
Isolation between field and bus.
The power supply
connetion protection function and surge absorption
function
The combination of hardware filtering and software
filtering is adopted
The module adopts 24V DC power supply.
119
Order No.
MAT-LC-AIS-04
MAT-LC-AQS-04
AQS-04
110mA
40mA
Description
terminal provides reverse
