Cpu Input Function; Digital Input - SMB MAT-LC-C Series User Manual

SF indicator (red)
BF indicator (red)
RUN indicator (green)
STOP indicator (yellow)
Network port communication indicator
Link1 indicator (green)
SPEED1 indicator (yellow)
Link2 indicator (green)
SPEED2 indicator (yellow)
I0.0~I1.1 (green)
Expanded I/O capability
1 CPU supports the number
of ETC-00 slaves
Number
supported by each ETC-00
Power-down retention
Clock power-down hold time
Programming software
Programming package
Programming language
Motion Controller Features
Supported Motion Controller
Features
5.2

CPU Input Function

5.2.1

Digital Input

The MAT-LC-CXX series C06/C07 motion controller integrates 10 digital inputs, and its input
characteristics are shown in the table below.
Table 5-3 Digital input characteristics of C06/C07 motion controller
Digital input feature
Native integrated IO points
Input type
Rated voltage
Input voltage range
Surge voltage
supply
On: System failure; Off: No error
On: bus fault; off: no error
On: the system is running; off: the system is stopped
On: the system is stopped; off: the system is running
On: Connected; Off: Not connected
On: 100Mbps; Off: 10Mbps
On: Connected; Off: Not connected
On: 100Mbps; Off: 10Mbps
On: signal input; off: no signal input
Up to 128
of modules
Supports up to 8 modules
After the C06/C07 is connected to an external battery, the
power-off retention time is typically more than 2 years (for the
ordering information of the external battery, see I Ordering
Information)
CODESYS V3 (SP18 Patch6 version)
Programming
CFC/FBD/LD/IL/ST/SFC
LC-C06：SoftMotion
LC-C07：SoftMotion and CNC
10
Sink/Source
24V DC
20.4~28.8V DC
35V DC for 0.5s
languages according
35
to IEC61131-3:
