SMB MAT-LC-C Series User Manual page 120

Analog input module
T Item
a Input type
b
Input points
l
Input scale
e
Voltage
Current
C
Max input voltage
-
Max input current
1
Input impedance
3
Voltage
Current
S
Data format
p
e
Input step response
c
Module update frequency (all
i
channels)
f
i
Common mode suppression
c
Channel crosstalk
a
Common mode voltage
t
i
Resolution
o
Measuring principle
n
Measurement error
Disconnection detection(only
o
for 4~20mA)
f
Isolation
Field to logic
a
24VDC to logic
n
Diagnosis
a
Over negative range
l
Over positive range
o
Without power
g
Voltage or current (differential input)
4
Unipolar: 0~5V，0~10V, bipolar: ±2.5V，±5V
0~20mA，4~20mA
30V DC
40mA
≥2MΩ
250Ω
Voltage: 0~+32000 (unipolar), -32000~+32000 (bipolar)
Current: 0~+32000
4-channel 5ms (max)
4-channel supports 200Hz、100Hz、50Hz、20Hz、10Hz
configuration
Default：50Hz for all channels
＞40dB
＞60dB
-12V≤ Signal voltage + Common mode voltage ≤+12V
Unipolar: 12bit
Bipolar: 11bit+ sign bit
Successive approximation
0.5% (Max)
Disconnection calibration: -32768， 32767 Two values
(optional)
500V AC
500V AC
Unipolar: 0 Bipolar: -32768
Unipolar: 32760 Bipolar: 32752
32736
120
AIS-04
