Table A-87: ADSP-SC58x LP0 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x30FFE018 LP0_TXIN_SHDW
0x30FFE01C LP0_TXOUT_SHDW
Table A-88: ADSP-SC58x LP1 MMR Register Addresses
Memory Map- Register Name
ped Address
0x30FFE100 LP1_CTL
0x30FFE104 LP1_STAT
0x30FFE108 LP1_DIV
0x30FFE110 LP1_TX
0x30FFE114 LP1_RX
0x30FFE118 LP1_TXIN_SHDW
0x30FFE11C LP1_TXOUT_SHDW
Table A-89: ADSP-SC58x M6CPH0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x310C5000 M6CPH0_CTL
0x310C5038 M6CPH0_WRMOD
0x310C503C M6CPH0_RDMOD
0x310C5040 M6CPH0_WRINDX
0x310C5044 M6CPH0_RDINDX
0x310C5058 M6CPH0_WRCNT
0x310C505C M6CPH0_RDCNT
0x310C5080 M6CPH0_DATA
0x310C5084 M6CPH0_KEY_HI
0x310C5088 M6CPH0_KEY_LO
0x310C508C M6CPH0_ENGINE_CTL
0x310C5090 M6CPH0_ENCRSZ
0x310C5094 M6CPH0_STAT
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
LP0 Shadow Input Transmit Buffer Register
LP0 Shadow Output Transmit Buffer Register
Description
LP1 Control Register
LP1 Status Register
LP1 Clock Divider Value Register
LP1 Transmit Buffer Register
LP1 Receive Buffer Register
LP1 Shadow Input Transmit Buffer Register
LP1 Shadow Output Transmit Buffer Register
Description
M6CPH0 M6 Wrapper Control register
M6CPH0 Write DMA Modifier
M6CPH0 Read DMA Modifier
M6CPH0 Memory Write Index
M6CPH0 Memory Read Index
M6CPH0 Write DMA Counter
M6CPH0 Read DMA Counter
M6CPH0 M6 Cipher Engine Data Register
M6CPH0 M6 Cipher Engine Key High Register
M6CPH0 M6 Cipher Engine Key Low Register
M6CPH0 M6 Cipher Engine Control Register
M6CPH0 M6 Cipher Engine Encryption size register
M6CPH0 M6 Cipher Engine status register
ADSP-SC58x Register List
Reset Value
0x00000000
0x00000000
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
A–127
