Analog Devices ADSP-SC58 Series Hardware Reference Manual page 3809

ADSP-SC58x Register List
Table A-92: ADSP-SC58x MSI0 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x3101005C MSI0_TCBCNT
0x31010060 MSI0_TBBCNT
0x31010064 MSI0_DEBNCE
0x31010080 MSI0_BUSMODE
0x31010084 MSI0_PLDMND
0x31010088 MSI0_DBADDR
0x3101008C MSI0_IDSTS
0x31010090 MSI0_IDINTEN
0x31010094 MSI0_DSCADDR
0x31010098 MSI0_BUFADDR
0x31010100 MSI0_CDTHRCTL
0x31010110 MSI0_ENSHIFT
Table A-93: ADSP-SC58x OTPC0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31011004 OTPC0_STAT
0x3101102C OTPC0_SECU_STATE
Table A-94: ADSP-SC58x PADS0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31004404 PADS0_PCFG0
0x31004460 PADS0_DAI0_IE
0x31004464 PADS0_DAI1_IE
Table A-95: ADSP-SC58x PCG0 MMR Register Addresses
Memory Map- Register Name
ped Address
0x310C9300 PCG0_CTLA0
0x310C9304 PCG0_CTLA1
0x310C9308 PCG0_CTLB0
0x310C930C PCG0_CTLB1
A–130
Description
MSI0 Transferred CIU Card Byte Count Register
MSI0 Transferred Host to BIU-FIFO Byte Count Register 0x00000000
MSI0 Debounce Count Register
MSI0 Bus Mode Register
MSI0 Poll Demand Register
MSI0 Descriptor List Base Address Register
MSI0 Internal DMA Status Register
MSI0 Internal DMA Interrupt Enable Register
MSI0 Current Host Descriptor Address Register
MSI0 Current Buffer Descriptor Address Register
MSI0 Card Threshold Control Register
MSI0 Enable Phase Shift Register
Description
OTPC0 OTP Status Register
OTPC0 OTP Security State Register
Description
PADS0 Peripheral PAD Configuration0 Register
PADS0 DAI0 Port Input Enable Control Register
PADS0 DAI1 Port Input Enable Control Register
Description
PCG0 Precision Clock A Control 0 Register
PCG0 Precision Clock A Control 1 Register
PCG0 Precision Clock B Control 0 Register
PCG0 Precision Clock B Control 1 Register
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Reset Value
0x00000000
0x00FFFFFF
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
Reset Value
0x00000000
0x00000001
Reset Value
0x00010009
0x00000000
0x00000000
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
