Table A-84: ADSP-SC58x L2CTL0 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x31080040 L2CTL0_ERRADDR0
0x31080044 L2CTL0_ERRADDR1
0x31080048 L2CTL0_ERRADDR2
0x3108004C L2CTL0_ERRADDR3
0x31080050 L2CTL0_ERRADDR4
0x31080054 L2CTL0_ERRADDR5
0x31080058 L2CTL0_ERRADDR6
0x3108005C L2CTL0_ERRADDR7
0x31080080 L2CTL0_ET0
0x31080084 L2CTL0_EADDR0
0x31080088 L2CTL0_ET1
0x3108008C L2CTL0_EADDR1
Table A-85: ADSP-SC58x L2CTL1 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31081000 L2CTL1_CTL
0x31081010 L2CTL1_STAT
0x31081014 L2CTL1_RPCR
0x31081018 L2CTL1_WPCR
0x31081024 L2CTL1_RFA
0x31081040 L2CTL1_ERRADDR0
0x31081044 L2CTL1_ERRADDR1
0x31081048 L2CTL1_ERRADDR2
0x3108104C L2CTL1_ERRADDR3
0x31081050 L2CTL1_ERRADDR4
0x31081054 L2CTL1_ERRADDR5
0x31081058 L2CTL1_ERRADDR6
0x3108105C L2CTL1_ERRADDR7
0x31081080 L2CTL1_ET0
0x31081084 L2CTL1_EADDR0
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
L2CTL0 ECC Error Address 0 Register
L2CTL0 ECC Error Address 1 Register
L2CTL0 ECC Error Address 2 Register
L2CTL0 ECC Error Address 3 Register
L2CTL0 ECC Error Address 4 Register
L2CTL0 ECC Error Address 5 Register
L2CTL0 ECC Error Address 6 Register
L2CTL0 ECC Error Address 7 Register
L2CTL0 Error Type 0 Register
L2CTL0 Error Type 0 Address Register
L2CTL0 Error Type 1 Register
L2CTL0 Error Type 1 Address Register
Description
L2CTL1 Control Register
L2CTL1 Status Register
L2CTL1 Read Priority Count Register
L2CTL1 Write Priority Count Register
L2CTL1 Refresh Address Register
L2CTL1 ECC Error Address 0 Register
L2CTL1 ECC Error Address 1 Register
L2CTL1 ECC Error Address 2 Register
L2CTL1 ECC Error Address 3 Register
L2CTL1 ECC Error Address 4 Register
L2CTL1 ECC Error Address 5 Register
L2CTL1 ECC Error Address 6 Register
L2CTL1 ECC Error Address 7 Register
L2CTL1 Error Type 0 Register
L2CTL1 Error Type 0 Address Register
ADSP-SC58x Register List
Reset Value
0x20080000
0x20080000
0x20080000
0x20080000
0x20080000
0x20080000
0x20080000
0x20080000
0x00000000
0x20000000
0x00000000
0x20000000
Reset Value
0x00000000
0x01000000
0x00000F0F
0x00000F0F
0x20180000
0x20180000
0x20180000
0x20180000
0x20180000
0x20180000
0x20180000
0x20180000
0x20180000
0x00000000
0x20100000
A–125
