Parameters
16-73 Counter B
Range: Function:
0 [-32768 - View the present value of Counter B. Counters
*
32767 ] are useful as comparator operands
(13-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (parameter group 5-1*) or by
using an SLC action (13-52 SL Controller Action).
16-79 Analog Output AO45
Range:
0 mA [0 - 20 mA]
*
3.12.6 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-86 FC Port REF 1
Range: Function:
0 [-32768 - 32767 ] View the last received reference from the
*
FC Port.

3.12.7 16-9* Diagnosis Readouts

16-90 Alarm Word
Range: Function:
0 [0 - 0xFFFFFFFFUL ] View the alarm word sent via the
*
serial communication port in hex
code.
16-91 Alarm Word 2
Range: Function:
0 [0 - 0xFFFFFFFFUL ] View the alarm word 2 sent via the
*
serial communication port in hex
code.
16-92 Warning Word
Range: Function:
0 [0 - 0xFFFFFFFFUL ] View the warning word sent via the
*
serial communication port in hex
code.
16-93 Warning Word 2
Range: Function:
0 [0 - 0xFFFFFFFFUL ] View the warning word 2 sent via the
*
serial communication port in hex
code.
®
VLT HVAC Basic Drive Programming Guide
16-94 Ext. Status Word
Range:
0
16-95 Ext. Status Word 2
Range:
0
Function:
®
MG18B222 - VLT is a registered Danfoss trademark
Function:
[0 - 0xFFFFFFFFUL ] Returns the extended status word sent
*
via the serial communication port in
hex code.
Function:
[0 - 0xFFFFFFFFUL ] Returns the extended status word 2
*
sent via the serial communication port
in hex code.
