Central Control Monitor
Centrifugal Pulse Parameters
Rate and Width are fixed and only Base must be set up.
1. Touch the Primary Pump icon to access the Primary Pump tab.
2. Select the Pulse subtab.
Arterial
Summary
100%
Servo
50%
Pulse
To Set the Base
1. Touch the Base button.
2. Use the large arrows to change the Base in increments of 10%.
3. Use the small arrows to change the Base in increments of 5%.
4. Touch the Base button again to store the new value. The recommended
minimum Base is 50%.
See the Centrifugal Control Unit chapter for details of Pulse mode operation.

Master and Follower Status Subtab

The Master and Follower Status subtab is a summary of the master and follower
pump names, the speed or flow ratio setting when the tab was opened, and the
connect status of the pumps.
Blood
Summary
Master Pump:
Servo
Follower Pump:
Master Status
Master-to-Follower Ratio: 4:1
If the master and follower pumps lose their connection to each other, these pumps
will stop automatically. The connection between these pumps must be reestablished
to continue operation in Master/Follower mode.
To reestablish pump connection:
1. Ensure both pumps are stopped.
2. Touch the Stop and Reconnect button.
• If reconnect is successful, the screen will display "Connect Status: PASS". The
display on each roller pump will indicate "M" or "F".
Cryst
Summary
Master Pump:
Servo
Follower Pump:
Follower Status
Master-to-Follower Ratio:
Pulse Control:
Rate: 60 BPM
60 BPM
85%
Base:
Auto Auto
50%
Width: 50%
Connect Status: PASS
Blood
Cryst
Connect Status: FAIL
Blood
Cryst
Stop and Reconnect
%
4-37
